Controls
- 4 Scenes
- 4 Relays - 10A (TV - 3 Rated)
- 2 Configurable Curtain Controllers
- 1 Input channel (Mechanical 2-way / sensors)
- Built-In IR Controller and blaster with 250 command storage
Nano 2M - 4S
hidden
Controls
- 4 Scenes
- 2 Universal Dimmers - 16A (TV - 3 Rated)
- 1 Input channel (Mechanical 2-way / sensors)
- Built-In IR Controller and blaster with 250 command storage
Nano 2M - 2D
hidden
Controls
- 1 Fan Regulator (Capacitive - 4 Steps)
- Built-In IR Controller and blaster with 250 command storage
Nano 2M - 1F
hidden
Controls
- 1 High Power Relay - 16 (TV - 5 Rated)
- Built-In IR Controller and blaster with 250 command storage
Nano 2M - 1 HPS
hidden
Nano Series - On board Features
Lighting & Dimming
Smooth and flicker free universal dimming (Leading / Trailing edge) supporting upto 350W dimmable LED Load.
Hum-Free Fan Speed
Four steps hum free fan speed control.
Curtain Control
On Board configurable curtain controller.
AC / Geyser
16A(TV - 5 Rated) high power relay to support AC / Geyser.
2 Way / Wired Sensor Input
Input Channels for Mechanical 2-way / wired sensor connection.
hidden
Nano Series - On board Features
Built-In IR Controller
Built in IR controller with learner (38kHz) for HVAC and multimedia controls.
Scenes & Scheduling
Scenario control, time scheduling and count down timer.
Adaptive Backlit
Night mode function for LED backlit
Voice Control & Apps
Supports voice control (Google home and Alexa compatible).
hidden
Nano Series - Connectivity
Wifi Mesh Technology
Wi-Fi mesh technology to reduce IP loads on routers.
BLE Connectivity
BLE support for 16 channel wireless intrusion sensor integration.
Direct Cloud Connectivity
Works without gateway.
hidden
High On Performance
High Voltage Protection
Wide Operating voltage range 85-285 Vac. Over Voltage cut-off above 285 Vac. With-standing voltage upto 440 Vac.
Surge Protection
Upto 6kv surge protection.
In-Rush Protection
TV-3 / TV-5 Rated Relays to handle High In-Rush loads.
